febi Brake Kit: Brake Discs + Brake Pads for HYUNDAI i30 PD and KIA Pro/Cee'd CD (Front)

febi Brake Kit: Brake Discs + Brake Pads for HYUNDAI i30 PD and KIA Pro/Cee'd CD (Front)

Item No.: A04652W197
Manufacturer: febi bilstein
part number: 108575, 170637

Items included:

2x Brake Disc Piece - febi bilstein 108575
1x Brake Pad Set, disc brake Set - febi bilstein 170637

item specifications

Component: Braking System
Quantity Unit: Piece
Brake Disc Type: internally vented
Fitting Position: Front Axle
Outer Diameter [mm]: 305
Surface: Coated
Bolt Hole Circle Ø [mm]: 114,3
Brake Disc Thickness [mm]: 25
Minimum thickness [mm]: 23,4
Thickness [mm]: 46,8
Centering Diameter [mm]: 69
Rim Hole Number: 5
Observe service information:
Number of mounting bores: 2

reference numbers - for comparison

ACKOJA - A52-40016 / A5240016
ACKOJA - A52-40016 / A5240016
ATE - 24.0125-0213.1 / 24012502131
ATE - 24.0125-0215.1 / 24012502151
BLUE PRINT - ADG043221
BOSCH - 0 986 479 E42 / 0986479E42
BOSCH - 0 986 T16 064 / 0986T16064
BREMBO - 09.D428.11 / 09D42811
BREMBO - 09.D428.1E / 09D4281E
BREMBO - 09.D428.1X / 09D4281X
DELPHI - BG4931C
DELPHI - BG4931C-18B1 / BG4931C18B1
ECORA - 4054224085752
EUROREPAR - 1667869580
EUROREPAR - 1671244980
EUROREPAR - 1684267880
FERODO - DDF2680C
FERODO - DDF2718C
FTE - 9082633
FTE - 9082810
HELLA - 8DD 355 126-541 / 8DD355126541
HELLA PAGID - 8DD 355 126-541 / 8DD355126541
HERTH+BUSS JAKOPARTS - J3300557
HERTH+BUSS JAKOPARTS - J3300557
HYUNDAI - 51712-C1000 / 51712C1000
HYUNDAI - 51712-C2000 / 51712C2000
HYUNDAI - 51712-D7000 / 51712D7000
HYUNDAI - 51712-J9100 / 51712J9100
HYUNDAI - 51712-N7050 / 51712N7050
JP Group - 3563103100
JURID - 563231JC-1 / 563231JC1
KIA - 51712-C1000 / 51712C1000
KIA - 51712-C2000 / 51712C2000
KIA - 51712-D7000 / 51712D7000
KIA - 51712-J9100 / 51712J9100
KIA - 51712-N7050 / 51712N7050
MAGNETI MARELLI - 360406167501
MAGNETI MARELLI - 361302040836
METZGER - 6110795
MEYLE - 37-83 521 0042/PD / 37835210042PD
OPTIMAL - BS-9506HC / BS9506HC
PAGID - 55922
PAGID - 55922NC
PAGID - T1378N-55922N-00 / T1378N55922N00
PAGID - T1378N-55922N-00 / T1378N55922N00
PAGID - T2061N-55922N-00 / T2061N55922N00
PAGID - T2061N-55922N-00 / T2061N55922N00
PAGID - T2693N-55922N-00 / T2693N55922N00
PAGID - T2693N-55922N-00 / T2693N55922N00
PAGID - T2705N-55922N-00 / T2705N55922N00
PAGID - T2705N-55922N-00 / T2705N55922N00
PAGID - T2883N-55922N-00 / T2883N55922N00
PAGID - T2883N-55922N-00 / T2883N55922N00
PAGID - T3158N-55922N-00 / T3158N55922N00
PAGID - T3158N-55922N-00 / T3158N55922N00
PAGID - T4183N-55922N-00 / T4183N55922N00
PAGID - T4183N-55922N-00 / T4183N55922N00
RAICAM - RD01583
SKF - VKBD 81296 V1 / VKBD81296V1
TEXTAR - 92292203
TEXTAR - 92292205
TOPRAN - 821 936 / 821936
TRW - DF6497S
TRW - DF8266
TRW - DF8266S
VALEO - 672790
ZIMMERMANN - 285.3531.20 / 285353120
ZIMMERMANN - 285.3531.52 / 285353152
ZIMMERMANN - 285.3531.53 / 285353153
febi bilstein - 108575
febi bilstein - 108669
febi bilstein - 4054224085752

item specifications

Component: Braking System
Quantity Unit: Set
WVA Number: 22804
Fitting Position: Front Axle
Wear Warning Contact: with acoustic wear warning
Supplementary Article/Supplementary Info 2: with anti-squeak plate
Supplementary Article/Supplementary Info 2: with fastening material
Thickness 1 [mm]: 18,9
Width [mm]: 59,6
Length [mm]: 148,8
Test Mark: ECE R90 Approved
Observe service information:

reference numbers - for comparison

ATE - 13.0460-5510.2 / 13046055102
ATE - 13.0470-5510.2 / 13047055102
BLUE PRINT - ADG042177
BOSCH - 0 986 424 862 / 0986424862
BREMBO - P 30 110 / P30110
BREMBO - P 30 110 / P30110
DELPHI - LP3385
DELPHI - LP5023EV
ECORA - 4054224706374
EUROREPAR - 1697648680
FTE - 9001344
FTE - 9011141
HELLA - 8DB 355 037-881 / 8DB355037881
HELLA PAGID - 8DB 355 037-881 / 8DB355037881
HERTH+BUSS JAKOPARTS - J3600562
HERTH+BUSS JAKOPARTS - J3600562
HYUNDAI - 58101-G4A00 / 58101G4A00
HYUNDAI - 58101-G4A10 / 58101G4A10
JURID - 574057J
KIA - 58101-G4A00 / 58101G4A00
KIA - 58101-G4A10 / 58101G4A10
MAGNETI MARELLI - 363700430110
MAGNETI MARELLI - 363916061235
METZGER - 1170929
MEYLE - 025 228 0420 / 0252280420
OPTIMAL - BP-12800 / BP12800
PAGID - T3158
PAGID - T3158
PAGID - T3158N
PAGID - T3158N
PAGID - T3158N-55922N-00 / T3158N55922N00
PAGID - T3158N-55922N-00 / T3158N55922N00
RAICAM - RA.1268.0 / RA12680
SKF - VKBP 81364 A / VKBP81364A
TEXTAR - 2280401
TRW - GDB2577
VALEO - 302733
VALEO - 610459
VALEO - 670209
ZIMMERMANN - 22804.200.2 / 228042002
febi bilstein - 170637
febi bilstein - 4054224706374
