Is this part compatible with my vehicle?

ZIMMERMANN Brake Discs + Pads for VW Multivan Transporter T5 T6 PR-2E3 (Front + Rear)

Item No.: PKT062W039

ZIMMERMANN Brake Discs + Pads for VW Multivan Transporter T5 T6 PR-2E3 (Front + Rear)

Item No.: PKT062W039
ZIMMERMANN
Items included:
  • 2x Brake Disc Piece - ZIMMERMANN
  • 1x Brake Pad Set, disc brake Set - ZIMMERMANN
  • 2x Brake Disc Piece - ZIMMERMANN
  • 1x Brake Pad Set, disc brake Set - ZIMMERMANN

Free lightning shipping in DE from 90€
Prioritized ordering possible
Questions about the item?
E-Mail-Icon
E-Mail

Brake Disc
item specifications
  • Bolt Hole Circle Ø [mm]: 120
  • Outer Diameter [mm]: 308
  • Surface: Coated
  • Component: Braking System
  • Brake Disc Type: vented
  • Fitting Position: Front Axle
  • Test Mark: ECE R90 APPROVED
  • Centering Diameter [mm]: 76
  • Quantity Unit: Piece
  • Rim Hole Number: 5
  • Hole Arrangement/Number: 6/5
  • Minimum thickness [mm]: 25,5
  • Processing: High-carbon
  • Brake Disc Thickness [mm]: 30
  • Weight [kg]: 10,25
  • Height [mm]: 56
reference numbers - for comparison
  • ATE - 24.0130-0114.1 / 24013001141
  • BOSCH - 0 986 479 211 / 0986479211
  • BOSCH - 0 986 479 B88 / 0986479B88
  • BREMBO - 09.D211.10 / 09D21110
  • BREMBO - 09.D211.11 / 09D21111
  • ECORA - 4250238744962
  • FERODO - DDF1253C-1 / DDF1253C1
  • HELLA - 8DD 355 109-661 / 8DD355109661
  • HELLA - 8DD 355 128-021 / 8DD355128021
  • JURID - 562234JC-1 / 562234JC1
  • RAICAM - RD01444
  • SHW Performance - VFX37013
  • TEXTAR - 92279505
  • TRW - DF4308S
  • VAG - 7E0 615 301 D / 7E0615301D
  • VAG - 7E0 615 301 D / 7E0615301D
  • VAG - 7H0 615 301 D / 7H0615301D
  • VAG - 7H0 615 301 D / 7H0615301D
  • VAG - JZW 615 301 E / JZW615301E
  • VOLKSWAGEN - 7E0 615 301 D / 7E0615301D
  • VOLKSWAGEN - 7H0 615 301 D / 7H0615301D
  • ZIMMERMANN - 4250238744962
  • ZIMMERMANN - 600.3223.20 / 600322320
  • ZIMMERMANN - 600.3223.52 / 600322352
Brake Pad Set, disc brake
item specifications
  • Component: Braking System
  • Width 1 [mm]: 155
  • Fitting Position: Front Axle
  • Number of wear indicators [per axle]: 1
  • Test Mark: ECE R90 APPROVED
  • WVA Number: 23746
  • Quantity Unit: Set
  • Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
  • Thickness [mm]: 18
  • Height 2 [mm]: 75
  • Width 2 [mm]: 156
  • Brake System: ATE
  • Wear Warning Contact: incl. wear warning contact
  • Height 1 [mm]: 73
reference numbers - for comparison
  • ATE - 13.0460-7236.2 / 13046072362
  • BOSCH - 0 986 494 107 / 0986494107
  • BREMBO - P 85 081 / P85081
  • BREMBO - P 85 081 / P85081
  • ECORA - 4250238739425
  • FERODO - FDB1642
  • FERODO - FVR1642
  • JURID - 573159J
  • TEXTAR - 2374602
  • TRW - GDB1555
  • VAG - 7H0 698 151 / 7H0698151
  • VAG - 7H0 698 151 B / 7H0698151B
  • VAG - 7H0 698 151 D / 7H0698151D
  • VAG - 7H0 698 151 F / 7H0698151F
  • VAG - 7H0 698 151 F / 7H0698151F
  • VAG - JZW 698 151 Q / JZW698151Q
  • VOLKSWAGEN - 7H0 698 151 F / 7H0698151F
  • ZIMMERMANN - 23467
  • ZIMMERMANN - 23746
  • ZIMMERMANN - 23746.185.1 / 237461851
  • ZIMMERMANN - 23835
  • ZIMMERMANN - 4250238739425
Brake Disc
item specifications
  • Bolt Hole Circle Ø [mm]: 120
  • Outer Diameter [mm]: 294
  • Surface: Coated
  • Component: Braking System
  • Brake Disc Type: Externally Vented
  • Fitting Position: Rear Axle
  • Test Mark: ECE R90 APPROVED
  • Centering Diameter [mm]: 77
  • Quantity Unit: Piece
  • Rim Hole Number: 5
  • Hole Arrangement/Number: 6/5
  • Minimum thickness [mm]: 19,5
  • Processing: High-carbon
  • Brake Disc Thickness [mm]: 22
  • Weight [kg]: 6,94
  • Height [mm]: 44
reference numbers - for comparison
  • ATE - 24.0122-0211.1 / 24012202111
  • BOSCH - 0 986 479 S06 / 0986479S06
  • BREMBO - 09.9582.11 / 09958211
  • ECORA - 4250238744986
  • FERODO - DDF1286C
  • HELLA - 8DD 355 109-701 / 8DD355109701
  • HELLA - 8DD 355 128-031 / 8DD355128031
  • HERTH+BUSS JAKOPARTS - J3310817
  • HERTH+BUSS JAKOPARTS - J3310817
  • JURID - 562262JC
  • RAICAM - RD00922
  • SHW Performance - VRX37117
  • TEXTAR - 92121403
  • TRW - DF4312
  • VAG - 7E0 615 601 D / 7E0615601D
  • VAG - 7E0 615 601 D / 7E0615601D
  • VAG - 7H0 615 601 B / 7H0615601B
  • VOLKSWAGEN - 7E0 615 601 D / 7E0615601D
  • ZIMMERMANN - 4250238744986
  • ZIMMERMANN - 600.3232.20 / 600323220
  • ZIMMERMANN - 600.3232.52 / 600323252
Brake Pad Set, disc brake
item specifications
  • Component: Braking System
  • Width [mm]: 116
  • Fitting Position: Rear Axle
  • Number of wear indicators [per axle]: 1
  • Test Mark: ECE R90 APPROVED
  • WVA Number: 23326
  • Quantity Unit: Set
  • Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
  • Supplementary Article/Supplementary Info 2: with anti-squeak plate
  • Thickness [mm]: 18
  • Height [mm]: 59
  • Brake System: LUCAS
  • Wear Warning Contact: incl. wear warning contact
reference numbers - for comparison
  • ATE - 13.0460-2882.2 / 13046028822
  • ATE - 13.0470-2882.2 / 13047028822
  • BOSCH - 0 986 494 108 / 0986494108
  • BOSCH - 0 986 494 583 / 0986494583
  • BOSCH - 0 986 495 094 / 0986495094
  • BREMBO - P 85 083 / P85083
  • BREMBO - P 85 083 / P85083
  • ECORA - 4250238737902
  • FERODO - FVR1644
  • HELLA - 8DB 355 011-531 / 8DB355011531
  • JURID - 573220J
  • JURID - 573220JC
  • RAICAM - RA.0819.0 / RA08190
  • TEXTAR - 2332602
  • TRW - GDB1557
  • VAG - 7E0 698 451 / 7E0698451
  • VAG - 7E0 698 451 A / 7E0698451A
  • VAG - 7E0 698 451 B / 7E0698451B
  • VAG - 7H0 698 451 / 7H0698451
  • VAG - 7H0 698 451 B / 7H0698451B
  • VAG - 7H0 698 451 C / 7H0698451C
  • VAG - 7H0 698 451 D / 7H0698451D
  • VAG - 7H0 698 451 E / 7H0698451E
  • VAG - 7H0 698 451 E / 7H0698451E
  • VAG - JZW 698 451 K / JZW698451K
  • VOLKSWAGEN - 7H0 698 451 E / 7H0698451E
  • ZIMMERMANN - 23326
  • ZIMMERMANN - 23326.175.1 / 233261751
  • ZIMMERMANN - 23326.175.2 / 233261752
  • ZIMMERMANN - 4250238737902
